Wilson Benesch A.C.T. C.60 & A.C.T. C.60 Limited Edition
|
The A.C.T. C.60 is a celebration of the original A.C.T. design, that preceded it fifteen years ago. The design documents a development path that is a logical sequence of steps towards the unobtainable - perfection.
The C.60 is also a celebration of the companies extensive manufacturing capability, and can be seen as a masterclass in modern engineering. The design elements are the end result of years of work and incorporate a broad range of exclusive technologies.
The design represents a significant new chapter of development that is, as you would expect completely unique. |
| Technische Daten: |
| Description: |
2.5 way, free space, ported enclosure, floor standing loudspeaker |
| Drive units: |
1 x 170mm Wilson Benesch W.B. One Bass unit
1 x 170mm Wilson Benesch W.B. One Bass Mid unit
1 x 25mm (1 in) Soft dome, hand painted silk, ultra linear Wilson Benesch specification tweeter
1 x Sphere Ultrasonic Generator, Gold plated Ceramic dome advanced tweeter |
| Low frequency loading: |
Bessel alignment of fourth order reflex. Double chamber, differential tuning |
| Frequency range: |
-6dB at 30Hz and 100kHz
-3dB at 33Hz and 80kHz |
| Frequency response: |
35Hz to 80kHz +- 2dB on axis |
| Sensitivity: |
89dB spl at 1metre on axis. 2.83V input |
| Impedance: |
6 Ohms nominal, 4.3 ohms minimum |
| Crossover: |
First order bass roll-off
Directly connected mid range drive unit
First order tweeter roll off with user selectable inputs to adjust sensitivity by 0, 1 or 2 dB |
| Crossover frequencies: |
500Hz / 20kHz |
| Internal wiring: |
Multi stranded military specification silver plated copper with teflon jacket. Platted by hand into exact lengths for each drive unit before being soldered point to point |
| Input connections: |
Each drive unit has its own Rhodium plated terminals. In the case of the tweeter additional terminals are provided to enable precise output levels |
| Power handling: |
240W peak unclipped programme |
| Maximum spl: |
112dB at 1 metre |
| Dimensions: |
H 1090 x W 230 x D 370mm |
| Internal volume: |
43.7 litre |
| Weight: |
56Kg |
| Standard Finishes: |
Regal SIlver, Black |
| Wood Satin Finishes: |
Oak, Cherry, Maple |
| Wood Gloss Finishes: |
Red Tulip, Birds Eye Maple, Red Birds Eye, Walnut, Ebonised Walnut, Burr Walnut |
| Limited Edition Finishes: |
Silver Grey, Black Carbon |
